High-Density Surge Protection for Large CCTV Video Systems
LY23 is a 16-port or 24-port BNC video surge protector designed for large-scale analog CCTV and centralized monitoring projects. Installed between field cameras and DVR, video matrix, control-room, or monitoring equipment, it helps limit transient overvoltage entering through multiple coaxial video lines while supporting stable continuous operation.
16-port and 24-port high-density protection options
Centralized protection for large analog CCTV systems
Transmisión de hasta 10Mbps con pérdida de inserción ≤0.2dB
DIN-rail design for security and monitoring cabinets
Aplicaciones adecuadas
LY23 is suitable for high-density analog video systems that require centralized surge protection for sixteen or twenty-four BNC coaxial channels.
Large CCTV Systems
Protects sixteen or twenty-four analog camera channels in large surveillance installations.
CCTV Central Stations
Suitable for centralized security rooms, DVR racks, monitoring cabinets, and video-control centers.
Building Security Systems
Protects high-density analog camera networks in commercial buildings, campuses, and public facilities.
Industrial Monitoring
Suitable for factories, logistics sites, warehouses, transport systems, and industrial control centers.
PREGUNTAS FRECUENTES
Common questions about LY23 16-port and 24-port BNC video surge protector selection and installation.
¿Para qué se utiliza el protector contra sobretensiones BNC de 16 puertos y 24 puertos LY23?
Proporciona protección contra sobretensiones centralizada para dieciséis o veinticuatro canales de video analógico CCTV conectados a través de cables coaxiales BNC.
¿Cuál es la diferencia entre las versiones de 16 puertos y 24 puertos?
La versión de 16 puertos protege dieciséis canales de video BNC independientes, mientras que la versión de 24 puertos protege veinticuatro canales en una carcasa centralizada.
¿Es adecuado el LY23 para operaciones de monitoreo continuo?
Está destinado a sistemas de vigilancia en funcionamiento continuo. La correcta puesta a tierra, dirección de instalación, compatibilidad de cables y la inspección regular son esenciales para un funcionamiento fiable.
Will the device affect video signal quality?
The listed insertion loss is no more than 0.2dB and the maximum transmission rate is 10Mbps. Compatibility should still be checked against the actual video format, impedance, cable length, and connected equipment.
Where should this multi-port SPD be installed?
Install it in a surveillance or control cabinet near the DVR, video matrix, receiver, monitor, or other centralized video equipment.
¿Qué se debe confirmar antes de ordenar?
Confirm the required number of channels, BNC connector arrangement, video format, operating voltage, cable impedance, cabinet space, grounding method, transmission distance, and required surge-withstand level.
